Astra Walker Icon Transformer a69.58.v2.h.tfr

ELECTRICAL DATA

Lamp wattage 35…105 W
Maximum output power 105 W
Line current 0.45 A 1)
Nominal voltage 220…240 V
Power factor 0.95 2)
Operating frequency 40 kHz 3)
Nominal output voltage 11.9 / 12.0 V 4)
Input voltage AC 198…264 V
Mains frequency 50…60 Hz
System wattage 111.00 W
Efficiency in full-load 94 %
Input voltage range 220…240 V
Galvanic isolation primary/secondary 4.00 kV5
Inrush current 0.5 A
